ESD Light duty castor - series 550, load capacity 65 kg
(Product No.: 502.100.EL)
Notice

ESD Light duty castor - series 550, load capacity 65 kg

dpvlink:
10726
Wheel Ø:
100 mm
Wheel width:
25 mm
axle hole:
8 mm
Hub length:
29 mm
Properties:
Further product information

16.35 CHF

1 PCE
Compare Compare
Notice
Product Info
The ESD caster wheel from Series 550 is distinguished by its high load capacity of 65 kg and a sturdy construction. The wheel with a diameter of 100 mm is made from a polypropylene wheel body and is equipped with a ball bearing, which allows for smooth movement. The tread made of black rubber is electrically conductive and meets the ESD standard DIN EN 61340-5-1, making it ideal for use in ESD-sensitive environments.
The wheel width is 25 mm and the hub length is 29 mm, while the axle hole measures 8 mm. The caster is temperature resistant from -20 to 60 °C and has a Shore hardness of 85 Shore A. Despite its robustness, the caster weighs only 148 g. It should be noted that plasticizer migration can cause discoloration of the floor. This product combines functionality with safety standards and is excellent for use in technically demanding areas.
Wheel Ø
Wheel Ø
100 mm
Wheel width
Wheel width
25 mm
axle hole
axle hole
8 mm
Hub length
Hub length
29 mm
Wheel bearing
Wheel bearing
Ball bearing
Wheel/castor type
Wheel/castor type
wheel
Conductivity
Conductivity
conductive
Load capacity (static)
Load capacity (static)
65 kg
Shore hardness
Shore hardness
85 Shore A
Tread
Tread
rubber
ESD
ESD
yes
Temperature resistance
Temperature resistance
-20 - 60 °C
Weight [g]
Weight [g]
148 g
Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 377
Complete Catalog 2023 - 2024

Product Family

Article image
Article description
Wheel Ø
Wheel width
axle hole
Hub length
Price
Compare
502.AK100.EL - ESD Light duty castor - series 550, load capacity 80 kg
502.AK100.EL
ESD Light duty castor - series 550, load capacity 80 kg
80
30
8
40
16.30 CHF
502.075.EL - ESD Light duty castor - series 550, load capacity 50 kg
502.075.EL
ESD Light duty castor - series 550, load capacity 50 kg
75 mm
23 mm
6 mm
29 mm
8.45 CHF
502.AK125.EL - ESD Light duty castor - series 550, load capacity 100 kg
502.AK125.EL
ESD Light duty castor - series 550, load capacity 100 kg
125
32
8
36
22.90 CHF
502.050.EL - ESD Light duty castor - series 550, load capacity 40 kg
502.050.EL
ESD Light duty castor - series 550, load capacity 40 kg
50 mm
18 mm
6 mm
22 mm
8.00 CHF
502.100.EL - ESD Light duty castor - series 550, load capacity 65 kg
502.100.EL
ESD Light duty castor - series 550, load capacity 65 kg
100 mm
25 mm
8 mm
29 mm
16.35 CHF
