Euro box trolley ESD 3 shelves 820 x 610 mm
ESD Euro Container Trolley 3-Shelves 820 x 610 mm
This ESD-compliant Euro container trolley is specially designed for use in the electronics industry, ideal as a transport, material, and picking trolley. The robust construction made of steel tubing and profile steel is electrostatically conductive powder-coated in slate grey RAL 7015. The shelves made of HPL composite board are also electrostatically conductive and kept in light grey. The innovative braking system by fetra, which is operated with a foot pedal, locks the rotation and swivel movement of the wheels to avoid hazardous situations.
Technical data:
- Dimensions (LxWxH): 935 x 666 x 1101 mm
- Load area: 820 x 610 mm
- Shelf heights: 264, 564, 864 mm, adjustable in 50 mm increments
- Shelf tilt for angled installation: 15° or 30°
- Wheel diameter: 125 mm, TPE-ESD tires
- Load capacity: Total 250 kg, per shelf 80 kg
- Material: Steel, shelves made of electrically conductive wood-based panel
- Color: dark grey
- Weight: 55 kg
- Surface resistance Rs: 10^5 - 10^7 Ω
The TOTALSTOP central braking system is available as an option at an additional cost.
Item number: 091.9391.ESD
This ESD-compliant Euro container trolley is specially designed for use in the electronics industry, ideal as a transport, material, and picking trolley. The robust construction made of steel tubing and profile steel is electrostatically conductive powder-coated in slate grey RAL 7015. The shelves made of HPL composite board are also electrostatically conductive and kept in light grey. The innovative braking system by fetra, which is operated with a foot pedal, locks the rotation and swivel movement of the wheels to avoid hazardous situations.
Technical data:
- Dimensions (LxWxH): 935 x 666 x 1101 mm
- Load area: 820 x 610 mm
- Shelf heights: 264, 564, 864 mm, adjustable in 50 mm increments
- Shelf tilt for angled installation: 15° or 30°
- Wheel diameter: 125 mm, TPE-ESD tires
- Load capacity: Total 250 kg, per shelf 80 kg
- Material: Steel, shelves made of electrically conductive wood-based panel
- Color: dark grey
- Weight: 55 kg
- Surface resistance Rs: 10^5 - 10^7 Ω
The TOTALSTOP central braking system is available as an option at an additional cost.
Item number: 091.9391.ESD
Details
- Depth [mm] Depth [mm]
- 935
- Width [mm] Width [mm]
- 666
- Height [mm] Height [mm]
- 1101
- Load capacity Load capacity
- 250 kg
- Wheel Ø Wheel Ø
- 125 mm
- Color Color
- dark grey
- Loading bed Loading bed
- 820 x 610 mm
- Shelf height Shelf height
- 264 - 864 mm
- Conductivity Conductivity
- dissipative
- Surface resistance Rs Surface resistance Rs
- 105 - 107 Ω
- Material Material
- steel
- Tires Tires
- TPE / ESD
- Shelves Shelves
- 3
- Weight Weight
- 55 kg
Downloads
- Please log in to download datasheets! :
- There are several datasheets for this product. Please log in!
Catalogues
Product Family
| Article image | Article description | Depth [mm] | Width [mm] | Height [mm] | Load capacity | Price | Compare |
|---|---|---|---|---|---|---|---|
|
091.9384.ESD Euro box trolley ESD 5 shelves 1240 x 610 mm | 1372 | 685 | 1686 | 300 kg | 1,894.00 CHF | |
|
091.9391.ESD Euro box trolley ESD 3 shelves 820 x 610 mm | 935 | 666 | 1101 | 250 kg | 982.00 CHF | |
|
091.9381.ESD Euro box trolley ESD 3 shelves 410 x 610 mm | 525 | 666 | 1101 | 250 kg | 793.00 CHF | |
| Show Compare List (0) | |||||||
