Totech drying cabinets

Totech drying cabinets
Acrylic drying cabinet ESDA 201-00
Shelves: 2 / Volume: 200 l / Width [mm]: 574 mm / Height [mm]: 750 mm / Depth [mm]: 517 mm /
TOTECH-ESD Acrylic - Drying cabinet ESDA 201-00
without drying unit
High-quality acrylic drying cabinet

Outer mass (BHT): 574 x750 x 517mm
Inner mass (BHT): 560 x 730 x 480 mm
Effective volume:200 l
Weight: 23 kg
Doors: 1
Number of shelves: 2
Drying unit: optional U-4001
dpvlink
27263

Product No.: TO-ESDA-201-00
Price on request
Acrylic drying cabinet ESDA 402-00
Shelves: 5 / Volume: 400 l / Width [mm]: 574 mm / Height [mm]: 1692 mm / Depth [mm]: 517 mm /
Drying Cabinet
High-quality acrylic dry Cabinet

Optional drying unit
Dimensions (WHD): 574 x 1690 x 517mm
internal dimensions (WHD): 560 x 1480 x 480 mm
Effective volume : 400 l
weight: 59 kg
doors: 2
number of shelves: 5
optional dry unit: 1 x U-4001 rh ≤ 2%
dpvlink
27263

Product No.: TO-ESDA-402-00
Price on request
Acrylic drying cabinet ESDA 402-21
Shelves: 5 / Volume: 400 l / Width [mm]: 574 / Height [mm]: 1692 / Depth [mm]: 517 /
Drying Cabinet



Dimensions (WHD): _ mm
internal dimensions (WHD): _ mm
sensor accuracy: +/-_ % RH & +/-_ ° C
Effective volume: _ l
weight: _ kg
doors: _
number of shelves:
_ dry unit: _x _ for ≤ _ % RH
power consumption: _ W/h
dpvlink
27263

Product No.: TO-ESDA-402-21
Price on request
Acrylic drying cabinet ESDA 804-00
Shelves: 10 / Volume: 800 l / Width [mm]: 1152 / Height [mm]: 1692 mm / Depth [mm]: 517 mm /
Drying Cabinet



Dimensions (WHD): _ mm
internal dimensions (WHD): _ mm
sensor accuracy: +/-_ % RH & +/-_ ° C
Effective volume: _ l
weight: _ kg
doors: _
number of shelves:
_ dry unit: _x _ for ≤ _ % RH
power consumption: _ W/h
dpvlink
27263

Product No.: TO-ESDA-804-00
Price on request
Acrylic drying cabinet ESDA 804-21
Shelves: 10 / Volume: 800 l / Width [mm]: 1152 mm / Height [mm]: 1692 mm / Depth [mm]: 517 mm /
Drying Cabinet



Dimensions (WHD): _ mm
internal dimensions (WHD): _ mm
sensor accuracy: +/-_ % RH & +/-_ ° C
Effective volume: _ l
weight: _ kg
doors: _
number of shelves:
_ dry unit: _x _ for ≤ _ % RH
power consumption: _ W/h
dpvlink
27263

Product No.: TO-ESDA-804-21
Price on request
Drying storage cabinet HSD 1104-52
Shelves: 5 / Volume: 1179 l / Width [mm]: 1200 mm / Height [mm]: 1675 mm / Depth [mm]: 658 mm /
Dry Storage Cabinet ESD
Engineered for medium to long-term constant low
humidity storage of less than 1%RH

Dimensions (WHD): 1200 x 1840 x 658 mm
internal dimensions (WHD): 1190 x 1533 x 630 mm
Effective capacity: 1179 l
weight: 176 kgg
doors: 6 (lockable with key)
number of shelves: 5
dry unit: 1x U-2000 for ≤ 1% RH
power consumption: 70 W/h
dpvlink
27401

Product No.: TO-HSD-1104-52
Price on request
Drying storage cabinet HSD 1106-52
Shelves: 5 / Volume: 1179 l / Width [mm]: 1200 mm / Height [mm]: 1675 mm / Depth [mm]: 658 mm /
Dry Storage Cabinet ESD
Engineered for medium to long-term constant low
humidity storage of less than 1%RH

Dimensions (WHD): 1200 x 1840 x 658 mm
internal dimensions (WHD): 1190 x 1533 x 630 mm
Effective capacity: 1179 l
weight: 176 kgg
doors: 6 (lockable with key)
number of shelves: 5
dry unit: 1x U-2000 for ≤ 1% RH
power consumption: 70 W/h
dpvlink
27401

Product No.: TO-HSD-1106-52
Price on request
Drying cabinet HSD 1704-52
Shelves: 5 / Volume: 1700 l / Width [mm]: 1200 mm / Height [mm]: 1675 mm / Depth [mm]: 960 mm /
Dry Storage Cabinet ESD
Engineered for medium to long-term constant low
humidity storage of less than 1%RH

Dimensions (WHD): 1200 x 1840 x 658 mm
internal dimensions (WHD): 1190 x 1533 x 630 mm
Effective capacity: 1179 l
weight: 176 kgg
doors: 6 (lockable with key)
number of shelves: 5
dry unit: 1x U-2000 for ≤ 1% RH
power consumption: 70 W/h
dpvlink
27401

Product No.: TO-HSD-1704-52
Price on request
Drying cabinet MSD 1222-55
Shelves: 4 / Volume: 1200 l / Width [mm]: 1121 mm / Height [mm]: 2040 mm / Depth [mm]: 900 mm /
Modular drying cabinet (basic module)
can be extended by additional cabinet modules
become
Ideal for reel storage
External dimensions (WHD): 840 x 2040 x 900 mm
Internal dimensions (WHD): 830 x 1780 x 850/730 mm
Effective volume:1200 l
Weight: 140 kg
Doors: 2
Number of shelves: 4
Drying unit: U-5003 (<0.5 %rF)></0.5 %rF)>
Power consumption: 30 W/h
Heating (40°C): optional
dpvlink
27406

Product No.: TO-MSD-1222-55
Price on request
Additional cabinet MSD 1223
Shelves: 4 / Volume: 1255 l / Width [mm]: 840 mm / Height [mm]: 2040 mm / Depth [mm]: 900 mm /
modular drying cabinet, expansion module
can be extended dependable on your requirements


Outer dimensions (WHD): 840 x 2040 x 900 mm
Internal dimensions (WHD): 830 x 1780 x 850 mm
Effective Volume:1255 l
Weight: 140 kg
Doors: 2
Number of shelves: 4
Drying unit: optional
Energy consumption: 30 W/h
Heating (40°C): optional
dpvlink
27406

Product No.: TO-MSD-1223
Price on request
Drying storage cabinet SD+ 1104-22
Shelves: 5 / Volume: 1179 l / Width [mm]: 1200 mm / Height [mm]: 1675 mm / Depth [mm]: 658 mm /
Dry Storage Cabinet ESD
Engineered for medium to long-term constant low
humidity storage of less than 1%RH

Dimensions (WHD): 1200 x 1840 x 658 mm
internal dimensions (WHD): 1190 x 1533 x 630 mm
Effective capacity: 1179 l
weight: 176 kgg
doors: 6 (lockable with key)
number of shelves: 5
dry unit: 1x U-2000 for ≤ 1% RH
power consumption: 70 W/h
dpvlink
27413

Product No.: TO-SD+1104-22
Price on request
Drying storage cabinet SD+ 1106-22
Shelves: 5 / Volume: 1179 l / Width [mm]: 1200 mm / Height [mm]: 1675 mm / Depth [mm]: 658 mm /
Dry Storage Cabinet ESD
Engineered for medium to long-term constant low
humidity storage of less than 1%RH

Dimensions (WHD): 1200 x 1840 x 658 mm
internal dimensions (WHD): 1190 x 1533 x 630 mm
Effective capacity: 1179 l
weight: 176 kgg
doors: 6 (lockable with key)
number of shelves: 5
dry unit: 1x U-2000 for ≤ 1% RH
power consumption: 70 W/h
dpvlink
27413

Product No.: TO-SD+1106-22
Price on request
Drying storage cabinet SD+ 302-22
Shelves: 7 / Volume: 320 l / Width [mm]: 500 mm / Height [mm]: 1227 mm / Depth [mm]: 640 mm /
Dry Storage Cabinet ESD
Engineered for medium to long-term constant
low humidity storage of less than 2 %RH
Ethernet interface, incl. Totech Viewer software
Dimensions (WHD): 500 x 1127 x 640 mm
internal dimensions (WHD): 490 x 1124 x 594 mm
effective capacity: 320 l
weight: 68 kg
doors: 2 (lockable with key)
number of shelves: 7
dry unit: 1 x U 2000for ≤ 2% RH
power consumption: 24 W / h
dpvlink
27413

Product No.: TO-SD+302-22
Price on request
Drying storage cabinet SD 1104-21
Shelves: 5 / Volume: 1179 l / Width [mm]: 1200 mm / Height [mm]: 1675 mm / Depth [mm]: 765 mm /
Dry Storage Cabinet ESD
Engineered for medium to long-term constant low
humidity storage of less than 1%RH

Dimensions (WHD): 1200 x 1840 x 658 mm
internal dimensions (WHD): 1190 x 1533 x 630 mm
Effective capacity: 1179 l
weight: 176 kgg
doors: 6 (lockable with key)
number of shelves: 5
dry unit: 1x U-2000 for ≤ 1% RH
power consumption: 70 W/h
dpvlink
27417

Product No.: TO-SD-1104-21
Price on request
Drying storage cabinet SD 1106-21
Shelves: 5 / Volume: 1179 l / Width [mm]: 1200 mm / Height [mm]: 1675 mm / Depth [mm]: 765 mm /
Dry Storage Cabinet ESD
Engineered for medium to long-term constant low
humidity storage of less than 1%RH

Dimensions (WHD): 1200 x 1840 x 658 mm
internal dimensions (WHD): 1190 x 1533 x 630 mm
Effective capacity: 1179 l
weight: 176 kgg
doors: 6 (lockable with key)
number of shelves: 5
dry unit: 1x U-2000 for ≤ 1% RH
power consumption: 70 W/h
dpvlink
27417

Product No.: TO-SD-1106-21
Price on request
Drying storage cabinet SD 151-21
Shelves: 3 / Volume: 135 l / Width [mm]: 500 mm / Height [mm]: 630 mm / Depth [mm]: 580 mm /
Dry Storage Cabinet ESD
Engineered for medium to long-term constant low
humidity storage of less than 1%RH

Dimensions (WHD): 500 x 630 x 580 mm
internal dimensions (WHD): 490 x 560 x 530 mm
Effective capacity: 135 l
weight: 37 kg
doors: 1 (lockable with key)
number of shelves: 3
dry unit: 1x U-2000 for ≤ 1% RH
power consumption: 35 W/h
dpvlink
27417

Product No.: TO-SD-151-21
Price on request
1 to 16 (from a total of 27)
