ESD Parting inserts and partitions

ESD Parting inserts and partitions

In our product range you will find a wide selection of interlayers and parting inserts (partitions) for the use in transport containers. The combination is ideal for transporting different components susceptible to ESD. Available in 3 different materials for various requirements



PP cavity material:
- made of extruded polypropylene (PP)
- high abrasion resistance
- low weight



PS solid material:
- made of polystyrene (PS)
- high abrasion resistance
- high stability



PE foam:
- made of polyethylene foam (PE)
- abrasion-resistant and corrosion-free
- very low weight


Our standard dimensions are based on the most commonly used Euro transport containers.

If you don't find what you are looking for among our standard dimensions, please don't hesitate to ask us for customer-specific dimensions.



Read more...

Configurators:
Printing Interlayers / Parting Inserts
Configurators:
Parting Inserts

PP Partition length 553 mm / height 180 mm / grid 20 mm ESD
Compartments: 24 / Grid spacing [mm]: 20 mm / Slots: 23 / External support: no /
PP partition wall, 553 x 180 x 3 mm, grid 20 mm
Grid 24 x 20 mm (23 slots) , "EPAstore"
electrostatically conductive (DIN EN 61340-5-1)
without external support
dpvlink
4058

Product No.: 050.241.180.20
3.35 CHF
PP Partition length 353 mm / height 80 mm / grid 20 mm ESD
Compartments: 15 / Grid spacing [mm]: 20 mm / Slots: 14 / External support: no /
PP partition wall, 353 x 80 x 3 mm, spacing 20 mm
spacing 15 x 20 mm (14 slots)
electrostatically conductive (DIN EN 61340-5-1)
without external support , "EPAstore"
dpvlink
14868

Product No.: 050.240.080.20
1.55 CHF
PP Partition length 353 mm / height 180 mm / grid 20 mm ESD
Compartments: 15 / Grid spacing [mm]: 20 mm / Slots: 14 / External support: no /
PP partition wall, approx. 353 x 180 x 3 mm,
spacing 20 mm
spacing 15 x 20 mm (14 slots) "EPAstore"
electrostatically conductive (DIN EN 61340-5-1)
without external support
dpvlink
4048

Product No.: 050.240.180.20
2.15 CHF
PP Partition length 553 mm / height 80 mm / grid 20 mm ESD
Compartments: 24 / Grid spacing [mm]: 20 mm / Slots: 23 / External support: no /
PP partition wall, 553 x 80 x 3 mm, spacing 20 mm
spacing 24 x 20 mm (23 slots), "EPAstore"
electrostatically conductive (DIN EN 61340-5-1)
without external support
dpvlink
14855

Product No.: 050.241.080.20
2.10 CHF
PP Partition length 353 mm / height 120 mm / grid 20 mm ESD
Compartments: 15 / Grid spacing [mm]: 20 mm / Slots: 14 / External support: no /
PP partition wall, 353 x 120 x 3 mm, spacing 20 mm
spacing 15 x 20 mm (14 slots)
electrostatically conductive (DIN EN 61340-5-1)
without external support , "EPAstore"
dpvlink
4026

Product No.: 050.240.120.20
1.75 CHF
PP Partition length 553 mm / height 120 mm / grid 20 mm ESD
Compartments: 24 / Grid spacing [mm]: 20 mm / Slots: 23 / External support: no /
PP partition wall,
approx. 553 x 120 x 3 mm, grid 20 mm
Grid 24 x 20 mm (23 slots) , "EPAstore"
electrostatically conductive (DIN EN 61340-5-1)
without external support
dpvlink
4036

Product No.: 050.241.120.20
2.85 CHF
PP Partition length 353 mm / height 120 mm / grid 32 mm ESD
Compartments: 10 / Grid spacing [mm]: 32 mm / Slots: 9 / External support: no /
PP partition wall, 353 x 120 x 3 mm, spacing 32 mm
spacing 10 x 32 mm (9 slots)
electrostatically conductive (DIN EN 61340-5-1)
without external support ,"EPAstore"
dpvlink
4026

Product No.: 050.240.120.32
1.80 CHF
PP Partition length 353 mm / height 80 mm / grid 78 mm ESD
Compartments: 4 / Grid spacing [mm]: 78 mm / Slots: 5 / External support: yes /
PP partition wall, 353 x 80 x 3 mm, spacing 78 mm
spacing 4 x 78 mm (5 slots)
with external support AS = approx. 14 mm
volume conductive (DIN EN 61340-5-1)
dpvlink
14868

Product No.: 050.240.080.78
1.25 CHF
PS Partition length 353 mm / height 120 mm / grid 20 mm ESD
Compartments: 15 / Grid spacing [mm]: 20 mm / Slots: 14 / External support: no /
PS partition wall, 353 x 120 x 1.85mm, grid 20 mm
15 x grid 20 mm (14 slots)
Material: PS solid material, thickness 1.85mm
electrostatically conductive (DIN EN 61340-5-1)
dpvlink
14974

Product No.: 050.340.120.20
3.30 CHF
PCE:

PS Partition length 353 mm / height 80 mm / grid 20 mm ESD
Compartments: 15 / Grid spacing [mm]: 20 mm / Slots: 14 / External support: no /
PS partition wall, 353 x 80 x 1.85mm, grid 20 mm
15 x grid 20 mm (14 slots)
Material: PS solid material, thickness 1.85mm
electrostatically conductive (DIN EN 61340-5-1)
dpvlink
14964

Product No.: 050.340.080.20
2.40 CHF
PCE:

PS Partition length 553 mm / height 120 mm / grid 20 mm ESD
Compartments: 24 / Grid spacing [mm]: 20 mm / Slots: 23 / External support: no /
PS partition wall, 553 x 120 x 1.85mm, grid 20 mm
24 x grid 20 mm (23 slots)
Material: PS solid material, thickness 1.85mm
electrostatically conductive (DIN EN 61340-5-1)
dpvlink
15007

Product No.: 050.341.120.20
5.00 CHF
PCE:

PP Partition length 353 mm / height 80 mm / grid 55 mm ESD
Compartments: 6 / Grid spacing [mm]: 55 mm / Slots: 5 / External support: no /
PP partition wall, 353 x 80 x 3 mm, spacing 55 mm
spacing 6 x 55 mm (5 slots)
electrostatically conductive (DIN EN 61340-5-1)
without external support , "EPAstore"
dpvlink
14868

Product No.: 050.240.080.55
1.25 CHF
PP Partition length 553 mm / height 80 mm / grid 84 mm ESD
Compartments: 6 / Grid spacing [mm]: 84 mm / Slots: 7 / External support: yes /
PP partition wall, 553 x 80 x 3 mm, spacing 84 mm
spacing 6 x 84 mm (7 slots), "EPAstore"
with external support AS = approx. 14 mm
volume conductive (DIN EN 61340-5-1)
dpvlink
14855

Product No.: 050.241.080.84
1.75 CHF
PP Partition length 353 mm / height 180 mm / grid 32 mm ESD
Compartments: 10 / Grid spacing [mm]: 32 mm / Slots: 9 / External support: no /
PP partition wall, 353 x 180 x 3 mm, spacing 32 mm
spacing 10 x 32 mm (9 slots) "EPAstore"
electrostatically conductive (DIN EN 61340-5-1)
without external support
dpvlink
4048

Product No.: 050.240.180.32
2.25 CHF
PP Partition length 353 mm / height 80 mm / grid 20 mm with external supports ESD
Compartments: 14 / Grid spacing [mm]: 20 mm / Slots: 15 / External support: yes /
PP partition wall, 353 x 80 x 3 mm, spacing 20 mm
spacing 15 x 20 mm (15 slots)
with external support AS = approx. 14 mm
volume conductive (DIN EN 61340-5-1) "EPAstore"
dpvlink
14868

Product No.: 050.240.080.20.A
1.60 CHF
PS Partition length 553 mm / height 120 mm / grid 52 mm ESD
Compartments: 10 / Grid spacing [mm]: 52 mm / Slots: 9 / External support: no /
PS partition wall, 553 x 120 x 1.85mm, grid 52 mm
10 x grid 52 mm (9 slots)
Material: PS solid material, thickness 1.85mm
electrostatically conductive (DIN EN 61340-5-1)
dpvlink
15007

Product No.: 050.341.120.52
4.00 CHF
PCE:
