Adapter plate for TP / LN-100 for pneumatic cutting machine TP / LN-100
(Product No.: 415.901)
The image shows a technical device with a rectangular casing. At the top, there is a flat metal plate with several small components. On one side, a silver heat sink protrudes.

Adapter plate for TP / LN-100 for pneumatic cutting machine TP / LN-100

Adapter plate for TP / LN-100 for pneumatic cutting machine TP / LN-100

dpvlink:
5385
Further product information


Compare Compare
Notice / Inquire
Product Info

Adapter plate for TP / LN-100 for pneumatic cutting machine TP / LN-100

The adapter plate for the pneumatic cutting machine TP / LN-100 by Olamef enables precise cutting of terminals in loose radial components. This product is distinguished by its ability to handle longer section lengths, thereby supporting flexible adjustments to various project requirements. The machine ensures a straight cut without burring or deformation of the wire surface due to its high-quality mechanics. Thanks to the robust construction, it is possible to cut multiple components simultaneously, significantly increasing efficiency.
The cutting process is conveniently activated via a foot switch. Additionally, special custom cutting plates and further adapter plates are available upon customer request to optimally tailor the machine to specific needs. With minimal cutting dimensions of 3.2 mm in length and 0.3 mm in diameter, and fixed maximum dimensions, the cutting machine provides a reliable solution for precise cuts in production and manufacturing.
Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Product Family

TP / LN-100

Pneumatic cutting machine for loose radial components

With the pneumatic cutting machine TP / LN-100 the leads of loose radial components can be cut exactly.

The precise mechanism ensures a straight cut without causing an edge or a deformation of the wire surface.

The robust construction allows the simultaneous cutting of several components.
The cutting process starts after pressing the foot switch. An adapter plate as well as several special cutting plates are available on customer's request.

  L d
 Min. mm 3.2 0.3
 Max. mm fixed1


Article image
Article description
Price
Compare
415.900 - Pneumatic cutting machine TP / LN-100 standard
415.900
Pneumatic cutting machine TP / LN-100 standard
2,968.55 CHF
415.900.S - Pneumatic cutting machine TP / LN-100 customized
415.900.S
Pneumatic cutting machine TP / LN-100 customized
-
415.901 - Adapter plate for TP / LN-100 for pneumatic cutting machine TP / LN-100
415.901
Adapter plate for TP / LN-100 for pneumatic cutting machine TP / LN-100
-
Show Compare List (0)

This product is compatible with (for example):

The image shows a technical device with a rectangular casing. At the top, there is a flat metal plate with several small components. On one side, a silver heat sink protrudes.
Pneumatic cutting machine TP / LN-100 standard...
TP/LN-100 cutting machine for loose
radial components, pneumatic, incl. standard
cutting plate H/L = 3.2 mm, d = 0,.3-1.0 mm;
cutting surface 45 x 54 mm
(Model 36.0001 art. no…)
dpvlink
5385

2,968.55 CHF
Show product
The image shows a technical device with a rectangular casing. At the top, there is a flat metal plate with several small components. On one side, a silver heat sink protrudes.
Pneumatic cutting machine TP / LN-100 customized...
dpvlink
5385

Price on request
Show product
