Adapter plate for TP / LN-500.2 for pneumatic cutting machine TP / LN-500.2
(Product No.: 415.908)
The image shows a compact device with a rectangular casing. It has a metal surface, cooling fins on the top, and a front with a slider and multiple ports.

Adapter plate for TP / LN-500.2 for pneumatic cutting machine TP / LN-500.2

Adapter plate for TP / LN-500.2 for pneumatic cutting machine TP / LN-500.2

dpvlink:
5392
Further product information


Compare Compare
Notice / Inquire
Product Info

Adapter plate for TP / LN-500.2 for pneumatic cutting machine TP / LN-500.2

The adapter plate for the pneumatic cutting machine TP / LN-500.2, manufactured by Olamef, is specifically designed to enable precise cuts for wire thicknesses up to a diameter of 1.3 mm. This high-quality accessory is compatible with various section lengths (3.7 mm, 4.2 mm, 4.7 mm, and 5.2 mm) as well as wire thicknesses (0.5 mm, 1.0 mm, and 1.5 mm), making it a versatile tool in the processing of wire materials. The machine's angled cutting configuration allows for the precise cutting and processing of even the finest wire types. The minimum cutting length is 3.2 mm with a minimum wire thickness of 0.3 mm, making the machine also suitable for very fine cutting tasks. Ideal for technical buyers looking for a reliable solution for demanding cutting processes.
Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Product Family

TP / LN-500

The TP/LN-500 cuts with an inclined cutting blade and allows the cutting of wire thicknesses of up to a diameter of 1.3 mm.

Technical data TP/LN-500/1 standard

Performance:

up to. 3,000 components/hour

Dimensions:

250 x 100 x 100 mm

Weight:

5 kg

Compressed air:

6 bar

Cutting lengt:

3.2 mm (other lengths available on request)


  L d
 Min. mm 3.2 0.3
 Max. mm fixed1.3


Article image
Article description
Price
Compare
415.905 - Pneumatic cutting machine TP / LN-500 - standard
415.905
Pneumatic cutting machine TP / LN-500 - standard
3,114.70 CHF
415.907 - Pneumatic cutting machine TP / LN-500.2
415.907
Pneumatic cutting machine TP / LN-500.2
3,786.30 CHF
415.905.S - Pneumatic cutting machine TP / LN-500 - customized
415.905.S
Pneumatic cutting machine TP / LN-500 - customized
-
415.906 - Adapter plate for TP / LN-500 for pneumatic cutting machine TP / LN-500
415.906
Adapter plate for TP / LN-500 for pneumatic cutting machine TP / LN-500
-
415.907.S - Pneumatic cutting machine TP / LN-500.2 - customized
415.907.S
Pneumatic cutting machine TP / LN-500.2 - customized
-
415.908 - Adapter plate for TP / LN-500.2 for pneumatic cutting machine TP / LN-500.2
415.908
Adapter plate for TP / LN-500.2 for pneumatic cutting machine TP / LN-500.2
-
