Adapter plate for TP / LN-500 for pneumatic cutting machine TP / LN-500
(Product No.: 415.906)
The image shows a compact device with a rectangular casing. It has a metal surface, cooling fins on the top, and a front with a slider and multiple ports.

Adapter plate for TP / LN-500 for pneumatic cutting machine TP / LN-500

Adapter plate for TP / LN-500 for pneumatic cutting machine TP / LN-500

dpvlink:
5392
Further product information


Compare Compare
Notice / Inquire
Product Info

Adapter plate for TP / LN-500 for pneumatic cutting machine TP / LN-500

The adapter plate for the pneumatic cutting machine TP / LN-500 from Olamef is specifically designed to cut wire gauges up to a diameter of 1.3 mm with an angled cutting blade. This precision component is available for section lengths of 3.7 mm, 4.2 mm, 4.7 mm, and 5.2 mm, as well as in various thicknesses of 0.5 mm, 1.0 mm, and 1.5 mm. The minimum length for cutting is 3.2 mm with a minimum wire gauge of 0.3 mm. The adaptability of the adapter plate allows users to flexibly respond to different requirements, making it ideal for specialized cutting processes.
The robust construction ensures high reliability and durability in industrial use.
Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Product Family

TP / LN-500

The TP/LN-500 cuts with an inclined cutting blade and allows the cutting of wire thicknesses of up to a diameter of 1.3 mm.

Technical data TP/LN-500/1 standard

Performance:

up to. 3,000 components/hour

Dimensions:

250 x 100 x 100 mm

Weight:

5 kg

Compressed air:

6 bar

Cutting lengt:

3.2 mm (other lengths available on request)


  L d
 Min. mm 3.2 0.3
 Max. mm fixed1.3


Article image
Article description
Price
Compare
415.905 - Pneumatic cutting machine TP / LN-500 - standard
415.905
Pneumatic cutting machine TP / LN-500 - standard
3,114.70 CHF
415.907 - Pneumatic cutting machine TP / LN-500.2
415.907
Pneumatic cutting machine TP / LN-500.2
3,786.30 CHF
415.905.S - Pneumatic cutting machine TP / LN-500 - customized
415.905.S
Pneumatic cutting machine TP / LN-500 - customized
-
415.906 - Adapter plate for TP / LN-500 for pneumatic cutting machine TP / LN-500
415.906
Adapter plate for TP / LN-500 for pneumatic cutting machine TP / LN-500
-
415.907.S - Pneumatic cutting machine TP / LN-500.2 - customized
415.907.S
Pneumatic cutting machine TP / LN-500.2 - customized
-
415.908 - Adapter plate for TP / LN-500.2 for pneumatic cutting machine TP / LN-500.2
415.908
Adapter plate for TP / LN-500.2 for pneumatic cutting machine TP / LN-500.2
-
Show Compare List (0)

This product is compatible with (for example):

The image shows a compact device with a rectangular casing. It has a metal surface, cooling fins on the top, and a front with a slider and multiple ports.
Pneumatic cutting machine TP / LN-500 - standard...
TP LN 500 cutting machine for loose radial
components, pneumatic, incl. standard cutting
plate, cutting surface 52 x 43 mm, H = 3.2 mm,
0.3-1.3 mm
(Model 34.0001 + 340111)
dpvlink
5392

3,114.70 CHF
Show product
The image shows a compact device with a rectangular casing. It has a metal surface, cooling fins on the top, and a front with a slider and multiple ports.
Pneumatic cutting machine TP / LN-500 - customized...
dpvlink
5392

Price on request
Show product
