Dispensing needle standard without thread size 20 length 25.4 mm
(Product No.: 560088-1.0)
The image shows a gray syringe with a long, thin needle. The syringe has a wide front end and a narrow, straight needle attachment. It is depicted in a simplified manner.
The image displays a technical drawing of a screwdriver. The handle is at the top, the blade runs straight down. The shape is simple and minimalist.
Mobile Preview: The image shows a gray syringe with a long, thin needle. The syringe has a wide front end and a narrow, straight needle attachment. It is depicted in a simplified manner.
Mobile Preview: The image displays a technical drawing of a screwdriver. The handle is at the top, the blade runs straight down. The shape is simple and minimalist.
Notice / Inquire

Dispensing needle standard without thread size 20 length 25.4 mm

dpvlink:
2915
Size:
20
Internal Ø:
0.58 mm
Length :
25.4 mm
Color:
rose
Further product information

Minimum order:
50 PCE
1.20 CHF

excl. 8.1% tax

50 PCE
Compare Compare
Notice / Inquire
Product Info

Dispensing needle standard without thread size 20 length 25.4 mm

This standard dosing needle without thread, size 20 and a length of 25.4 mm, is ideal for precise dosing applications. The needle diameter is 0.58 mm and it is easily identifiable by its yellow marking. The robust plastic body combined with a stainless steel capillary ensures high durability and reliability in use. The packaging unit includes 50 pieces, enabling efficient storage and handling. This product combines functionality with quality to meet the demanding needs of technical purchasing.
Size
Size
20
Internal Ø
Internal Ø
0.58 mm
Length
Length
25.4 mm
Color
Color
rose
Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 539
Complete Catalog 2023 - 2024

Product Family

Dispensing needle standard (without thread)

Material: plastic body, capillary tube made of stainless steel,

Length: 25.4 mm (1")

Packaging unit: 50 pieces


Article image
Article description
Size
Internal Ø
Length
Color
Price
Compare
560088-1.0 - Dispensing needle standard without thread size 20 length 25.4 mm
560088-1.0
Dispensing needle standard without thread size 20 length 25.4 mm
20
0.58 mm
25.4 mm
rose
1.20 CHF
560090-1.0 - Dispensing needle standard without thread size 22 length 25.4 mm
560090-1.0
Dispensing needle standard without thread size 22 length 25.4 mm
22
0.41 mm
25.4 mm
blue
1.20 CHF
Show Compare List (0)
