The image displays a gray plastic mold with 16 rectangular indentations. The dimensions are 553 mm long, 353 mm wide, and 85 mm high. The mold has a flat top and is sturdy.
Vacuum-formed insert T-240 553 x 353 x 29 mm, 21 compartments ESD
(Product No.: 032.T-240)
The image displays a gray plastic mold with 16 rectangular indentations. The dimensions are 553 mm long, 353 mm wide, and 85 mm high. The mold has a flat top and is sturdy.
Notice / Inquire

Vacuum-formed insert T-240 553 x 353 x 29 mm, 21 compartments ESD

Vacuum-formed insert T-240 553 x 353 x 29 mm, 21 compartments ESD

dpvlink:
18912
Length :
553 mm
Width :
353 mm
Height :
29 mm
Properties:
Further product information
Imprinting / Printing for boxes
configure_now


Minimum order:
50 PCE
20.65 CHF

excl. 8.1% tax

50 PCE
Compare Compare
Notice / Inquire
Product Info

Vacuum-formed insert T-240 553 x 353 x 29 mm, 21 compartments ESD

The Licefa T-240 deep-drawing insert is a high-quality solution for the secure storage and transport of sensitive electronic components. With dimensions of 553 x 353 x 29 mm and 21 compartments each measuring 85 x 65 x 17 mm, this insert fits perfectly into containers measuring 600 x 400 mm.
The insert features reversible stacking and a practical handle recess, which simplifies handling. Particularly notable is the electrical conductivity of the material, which meets the standards of DIN EN 61340-5-1 and has a surface resistance of 10^3 to 10^5 Ω. This guarantees effective protection against electrostatic discharges (ESD).
The product from Licefa, a renowned manufacturer in this field, thus offers a safe and efficient solution for technical applications where the protection of sensitive components is paramount.
Length
Length
553 mm
Width
Width
353 mm
Height
Height
29 mm
Conductivity
Conductivity
conductive
Surface resistance Rs
Surface resistance Rs
103 - 105 Ω
Cavities
Cavities
21
Dimensions cavities
Dimensions cavities
85x65x17 mm
Suitable for containers
Suitable for containers
600x400 mm
Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 317
Complete Catalog 2023 - 2024
