The image displays a gray plastic tray with many small compartments. It has a rectangular shape with forty recessed areas to neatly organize objects.
Vacuum-formed insert T-242 553 x 353 x 40 mm, 27 compartments ESD
(Product No.: 032.T-242)
The image displays a gray plastic tray with many small compartments. It has a rectangular shape with forty recessed areas to neatly organize objects.
Notice

Vacuum-formed insert T-242 553 x 353 x 40 mm, 27 compartments ESD

Vacuum-formed insert T-242 553 x 353 x 40 mm, 27 compartments ESD

dpvlink:
18918
Length :
553 mm
Width [mm]:
353 mm
Height [mm]:
40 mm
Properties:
Further product information
Imprinting / Printing for boxes
configure_now


Minimum order:
10 PCE
24.10 CHF

excl. 8.1% tax

10 PCE
Compare Compare
Notice
Product Info

Vacuum-formed insert T-242 553 x 353 x 40 mm, 27 compartments ESD

The deep-drawing insert T-242 from Licefa is a highly functional solution for the safe storage and transport of sensitive electronic components. With dimensions of 553 x 353 x 40 mm and a total of 27 compartments, each measuring 107 x 47 x 22 mm, this product is specifically designed for containers sized 600 x 400 mm.
The insert is characterized by its electrical conductivity, which is standardized according to DIN EN 61340-5-1, with a surface resistance between 10^3 and 10^5 Ohm. This feature makes it ideal for use in ESD-sensitive environments to prevent static discharges.
Additionally, the deep-drawing insert offers practical features such as a recessed grip and the option for reversible stacking, which simplifies handling and storage. The robust construction from conductive plastic (Liastat) ensures durability and protection of the stored components.
Length
Length
553 mm
Width [mm]
Width
353 mm
Height [mm]
Height
40 mm
Conductivity
Conductivity
conductive
Surface resistance Rs
Surface resistance Rs
103 - 105 Ω
Cavities
Cavities
27
Dimensions cavities
Dimensions cavities
107x47x22 mm
Suitable for containers
Suitable for containers
600x400 mm
Common
Vacuum-formed inserts are specially shaped inserts or inserts made of plastic that are used in storage and transport containers to store sensitive or fragile items safely and securely.
Licefa's ESD vacuum-formed inserts offer a first-class solution for the safe and efficient storage of your sensitive electronic components. All inserts are made of electrically conductive material (Liastat).

Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 317
Complete Catalog 2023 - 2024
Configurators:
Imprinting / Printing for boxes

Product Family

Vacuum-formed inserts T-242

Article image
Article description
Length
Width [mm]
Height [mm]
Price
Compare
032.T-242 - Vacuum-formed insert T-242 553 x 353 x 40 mm, 27 compartments ESD
032.T-242
Vacuum-formed insert T-242 553 x 353 x 40 mm, 27 compartments ESD
553 mm
353 mm
40 mm
24.10 CHF
