Shelf RS1-F610
ESD shelf RS1-F610 ESD
1000 x 600 x 40 mm, plug-in system
Surface zinc plated + ESD coating light grey
Load capacity max. 140 kg / shelf
(without shelf holders)
dpvlink
16976

Product No.: RS1-F610.ESD
75.05 CHF
Storage box with corrugated base
Height [mm]: 105 mm / Width [mm]: 149 mm / Depth [mm]: 192 mm / Internal height: 90 mm / Internal width: 125 mm / Internal depth: 130 mm / Volume: 1.5 l / Load capacity : 5 kg /
ESD storage box 192 x 149 x 105 mm /
outside (LxWxH), corrugated base
electrically conductive (DIN EN 61340-5-1)
Part no. 1520-4 ESD
dpvlink
5339

Product No.: 050.150
13.55 CHF
Part bins ESD
Height [mm]: 70 mm / Width [mm]: 198 mm / Depth [mm]: 160 mm / Internal height: 62 mm / Internal width: 175 mm / Internal depth: 100 mm / Volume: 2.2 l / Load capacity : 5 kg / Dimensions outside [mm]: 160 x 198 x 70 /
ESD part bin 160 x 198 x 70 mm /
outside (DxWxH),.
electrically conductive (DIN EN 61340-5-1)
Part no. 30-2L-4 ESD
dpvlink
5355

Product No.: 050.170
11.60 CHF
ESD Storage box
Height [mm]: 200 mm / Width [mm]: 210 mm / Depth [mm]: 350 mm / Internal height: 190 mm / Internal width: 190 mm / Internal depth: 314 mm / Volume: 11,7 l /
ESD storage box 350 x 210 x 200 mm /
outside (DxWxH), electrically conductive
(DIN EN 61340-5-1)
dpvlink
23271

Product No.: SK4H.ESD
11.90 CHF
SMD reel rack type 300
Length [mm]: 850 mm / Width [mm]: 270 mm / Height [mm]: 175 mm / Reel diameter: 250 mm / Reels: 54 /
SMD reel rack type 300 / 250.850
Dimensions 850 x 270 x 175 mm LxWxH,
maximum 54 reels D = 250 mm
electrically conductive (DIN EN 61340-5-1)
dpvlink
7009

Product No.: 039.300.250.850
69.50 CHF
ESD Storage box
Height [mm]: 200 mm / Width [mm]: 310 mm / Depth [mm]: 500 mm / Internal height: 189 mm / Internal width: 281 mm / Internal depth: 455 mm / Volume: 25 l /
ESD storage box 500 x 310 x 200 mm /
outside (DxWxH), electrically conductive
(DIN EN 61340-5-1)
dpvlink
23271

Product No.: SK5.ESD
17.05 CHF
ESD Swivel castors with bolt hole 500, load capacity 50 kg
Wheel Ø: 80 mm / Total height: 101 mm /
ESD swivel castor 80 mm,
bolt hole diameter 12 mm,
Pressed steel bracket, electrically conductive

Wheel width: 30 mm
bolt hole: 12 mm
load capacity: 50 kg

A plasticizer diffusion can lead to a disoloration of the floor, hardness approx. 80 °-85 ° shore A
dpvlink
3234

Product No.: 523.080.EL
9.50 CHF
ESD Rack/material flow box
Width [mm]: 117 mm / Height [mm]: 90 mm / Depth [mm]: 500 mm / Internal width: 99 mm / Internal height: 88 mm / Internal depth: 471 mm / Volume: 4.2 l /
ESD rack/material flow box 500 x 117 x 90 mm/
outside (DxWxH), electrically conductive
(DIN EN 61340-5-1)
dpvlink
23253

Product No.: RK5109.ESD
6.60 CHF
DEPOFIX Classic storage box ESD
Height [mm]: 145 mm / Width [mm]: 200 mm / Depth [mm]: 350 mm / Internal height: 127 mm / Internal width: 182 mm / Internal depth: 280 mm / Additional: without rail suspension /
Storage box Depofix Classic
350x200x145 mm / 280x182x127 mm
IDP red, electrostatically dissipative
IDP = Inherently dissipative polymers
(DIN EN 61340-5-1)
dpvlink
10136

Product No.: 5321.3Z.rot
19.80 CHF
Basic rack type 100/50/200 ESD
D [mm]: 500 / W [mm]: 1024 / H [mm]: 2000 / Shelves: 6 / Load capacity : 150 kg /
Basic shelf type 100/50/200 ESD
6 ESD shelves 1000 x 500 mm
Dimensions: 500 x 1024 x 2000 mm / Lxwxh
load capacity approx. 150kg/shelf,
light grey RAL 7035 (ESD version, DIN EN 61340-5-1)

- load capacity of up to 150 kg / shelf, bay load 1000 kg
- shelfs adjustable in 28 mm steps
- incl. 2 diagonal braces (cross bracing)
- easy assembly / plug-in system
dpvlink
19267

Product No.: 315.49001
460.00 CHF
Storage box ESD 75 x 125 x 170 mm
Height [mm]: 75 mm / Width [mm]: 125 mm / Depth [mm]: 173 mm / Internal height: 65 mm / Internal width: 108 mm / Internal depth: 124 mm / Volume: 1.0 l /
ESD storage box 75 x 125 x 170 mm (HxWxD)
volume conductive (DIN EN 61340-5-1 + IEC)
Part no. BIN3-160 ESD
dpvlink
1893

Product No.: 050.2601
8.60 CHF
DEPOFIX Classic storage box ESD
Height [mm]: 125 mm / Width [mm]: 145 mm / Depth [mm]: 235 mm / Internal height: 108 mm / Internal width: 127 mm / Internal depth: 180 mm /
Storage box Depofix Classic
235 x 145 x 125 mm / 180 x 127 x 108 mm,
IDP yellow electrostatically dissipative
IDP = Inherently dissipative polymers
(DIN EN 61340-5-1)
dpvlink
10136

Product No.: 5321.4.gelb
12.05 CHF
Drawer with corrugated base ESD
Width [mm]: 92 mm / Height [mm]: 82 mm / Depth [mm]: 400 mm / Internal width: 75 mm / Internal height: 70 mm / Internal depth: 357 mm / Volume: 1.9 l /
ESD drawer 400 x 92 x 82 mm outside
(LxWxH)
electrically conductive (DIN EN 61340-5-1)
Part no. 4010-4 ESD
Scope of delivery: drawer, label, transparent screen
dpvlink
5296

Product No.: 050.125
13.35 CHF
Extension rack 100/50/200 ESD
D [mm]: 500 / W [mm]: 1004 / H [mm]: 2000 / Shelves: 6 / Load capacity : 150 kg /
Extension shelf type 100/50/200 ESD
6 ESD shelves 1000x500 mm / WxD
Dimensions:500 x 1004 x 2000 / Lxwxh
load capacity approx. 150kg/shelf,
light grey RAL 7035 (ESD version, DIN EN 61340-5-1)

- load capacity of up to 150 kg / shelf, bay load 1000 kg
- shelfs adjustable in 28 mm steps
- incl. 2 diagonal braces (cross bracing)
- easy assembly / plug-in system
dpvlink
19278

Product No.: 325.49001
370.00 CHF
Drawer with corrugated base ESD
Width [mm]: 92 mm / Height [mm]: 82 mm / Depth [mm]: 500 mm / Internal width: 75 mm / Internal height: 70 mm / Internal depth: 457 mm / Volume: 2.4 l /
ESD drawer 500 x 92 x 82 mm outside
(LxWxH)
electrically conductive (DIN EN 61340-5-1)
Part no. 5010-4 ESD
Scope of delivery: drawer, label, transparent screen
dpvlink
5296

Product No.: 050.132
16.50 CHF
ESD Swivel castors with bolt hole 500, load capacity 100 kg
Load capacity (static): 100 kg / Wheel Ø: 125 mm / Total height: 153,5 mm /
ESD swivel castor 125 mm,
bolt hole diameter. 12 mm,
Pressed steel bracket, electrically conductive

Wheel width: 38 mm
bolt hole: 12 mm
load capacity: 100 kg

A plasticizer diffusion can lead to a disoloration of the floor, hardness approx. 80 °-85 ° shore A
dpvlink
3234

Product No.: 523.125.EL
19.75 CHF
81 to 96 (from a total of 422)
