ESD Wheels and castors

ESD Wheels and castors

ESD Swivel castors with top plate - double stop 500, load capacity 50 kg
Load capacity (static): 50 kg / Wheel Ø: 80 mm / Total height: 100 mm /
ESD swivel castor 80 mm, double stop
top plate 105x80mm,
Pressed steel bracket, electrically conductive

Wheel width: 30 mm
bores/plate: 80x60 mm
load capacity: 50 kg

A plasticizer diffusion can lead to a disoloration of the floor, hardness approx. 80 °-85 ° shore A
dpvlink
3280

Product No.: 524.080.DS.EL
12.45 CHF
ESD Swivel castors with bolt hole - double stop (DS) 500, load capacity 70 kg
Wheel Ø: 100 mm / Total height: 126 mm /
ESD swivel castor 100 mm, double stop,
bolt hole diameter 12 mm
Pressed steel bracket, electrically conductive

wheel width: 30 mm
bolt hole: 12 mm
load capacity: 70 kg

A plasticizer diffusion can lead to a disoloration of the floor, hardness approx. 80 °-85 ° shore A
dpvlink
3256

Product No.: 523.100.DS.EL
15.05 CHF
ESD Fixed castor with top plate 600, load capacity 175 kg
Load capacity (static): 175 kg / Wheel Ø: 100 mm / Total height: 125 mm /
ESD fixed castor 100mm, top plate 100x85mm,
thermoplastic rubber tread, non-marking grey,
wheel body made of polypropylene,
electrically conductive (DIN EN 61340-5-1)

Wheel width: 32 mm
bores/plate: 80 x 60 mm
load capacity: 100 kg
dpvlink
8051

Product No.: 625.100.ELS
15.60 CHF
ESD Swivel castor with bolt hole - "stop-fix" 600, load capacity 175 kg
Load capacity (static): 175 kg / Wheel Ø: 100 mm / Total height: 125 mm /
ESD swivel castor 100mm,with brake "stop fix SF"
bolt hole diameter 13 mm, thermoplastic
rubber tread, non-marking grey,
wheel body made of polypropylene,
electrically conductive (DIN EN 61340-5-1)

Plate diameter: 70 mm
wheel width: 32 mm
bolt hole: 13 mm
load capacity: 100 kg
dpvlink
8039

Product No.: 623.100.SF.ELS
30.10 CHF
ESD Swivel castors with bolt hole 500, load capacity 70 kg
Load capacity (static): 70 kg / Wheel Ø: 100 mm / Total height: 126 mm /
ESD swivel castor 100 mm,
bolt hole diameter. 12 mm,
Pressed steel bracket, electrically conductive

Wheel width: 30 mm
bolt hole: 12 mm
load capacity: 70 kg

A plasticizer diffusion can lead to a disoloration of the floor, hardness approx. 80 °-85 ° shore A
dpvlink
3234

Product No.: 523.100.EL
11.80 CHF
ESD Swivel castors with bolt hole - double stop (DS) 500, load capacity 100 kg
Load capacity (static): 100 kg / Wheel Ø: 125 mm / Total height: 153,5 mm /
ESD swivel castor 125 mm, double stop
bolt hole diameter 12 mm,
Pressed steel bracket, electrically conductive

Wheel width: 38 mm
bolt hole: 12 mm
load capacity: 100 kg

A plasticizer diffusion can lead to a disoloration of the floor, hardness approx. 80 °-85 ° shore A
dpvlink
3256

Product No.: 523.125.DS.EL
22.65 CHF
ESD Light duty castor - series 550, load capacity 50 kg
Wheel Ø: 75 mm / Wheel width: 23 mm / axle hole: 6 mm / Hub length: 29 mm /
ESD wheel 75 mm, series 550 / apparatus castor
Rubber tires
electrically dissipative

Wheel width: 23 mm
hub length:27 mm
bore: 6 mm
load capacity: 50 kg

A plasticizer diffusion can lead to a disoloration of the floor, hardness approx. 80 °-85 ° shore A
dpvlink
10726

Product No.: 502.075.EL
8.45 CHF
ESD Fixed castors with top plate 500, load capacity 100 kg
Load capacity (static): 100 kg / Wheel Ø: 125 mm / Total height: 155 mm /
ESD fixed castor 125 mm,
top plate 102x87 mm,
pressed steel bracket, electrically conductive

Wheel width: 30 mm
bores/plate: 80x60 mm
load capacity: 100 kg

A plasticizer diffusion can lead to a disoloration of the floor, hardness approx. 80 °-85 ° shore A
dpvlink
3298

Product No.: 525.125.EL
14.85 CHF
ESD Light duty swivel castor with bolt hole 550, load capacity 110 kg, heavy version
Wheel Ø: 125 /
ESD swivel castor 125 mm,
Series 550 / apparatus castor
Back hole, sheet steel housing,
with thread protection, rubber tyres black,
electrically conductive
Wheel width: 32 mm
back hole: 12.2 mm
loading capacity: 100 kg

A plasticizer diffusion can lead to a contact discoloration of the floor, approx. 80 ° -85 ° Shore A
dpvlink
10754

Product No.: 503.AK125.EL
29.25 CHF
ESD Wheels, solid rubber 500, load capacity 100 kg
Wheel Ø: 125 / Wheel width: 38 / axle hole: 15 / Hub length: 50 /
ESD wheel 125 mm, electrically dissipative
solid rubber tires with steel rim


Wheel width: 38 mm
hub length: 50 mm
hole: 15 mm
load capacity: 100 kg

A plasticizer diffusion can lead to a disoloration of the floor, hardness approx. 80 °-85 ° shore A
dpvlink
3194

Product No.: 522.125.EL
10.80 CHF
ESD Swivel castors with top plate - double stop 500, load capacity 205 kg
Load capacity (static): 205 kg / Wheel Ø: 200 mm / Total height: 235 mm /
ESD swivel castor 200 mm, double stop
top plate 135x110 mm,
Pressed steel bracket, electrically conductive

Wheel width: 50 mm
bores/plate: 105x80 mm
load capacity: 205 kg

A plasticizer diffusion can lead to a disoloration of the floor, hardness approx. 80 °-85 ° shore A
dpvlink
3280

Product No.: 524.200.DS.EL
50.55 CHF
ESD Light duty swivel castor with top plate - "stop-fix" 650, load capacity 125 kg
Load capacity (static): 125 kg / Wheel Ø: 75 mm / Total height: 100 mm /
ESD apparatus swivel castor 75 mm, with brake
"stop-fix SF", top plate 60 x 60 mm,
thermoplastic rubber tread, non-marking grey
wheel body made of polypropylene,.
electrically conductive (DIN EN 61340-5-1)

Wheel width: 25 mm
bores/plate: 38x38 to 48x48 mm
load capacity: 75 kg
dpvlink
10706

Product No.: 604.075.SF.ELS
16.10 CHF
ESD Swivel castors with bolt hole 600, load capacity 165 kg
Load capacity (static): 165 kg / Wheel Ø: 80 mm / Total height: 102 mm /
ESD swivel castor 80 mm, back hole diameter 13 mm
thermoplastic rubber tread, non-marking grey
wheel body made of polypropylene,
electrically conductive (DIN EN 61340-5-1)

Plate diameter: 70 mm
wheel width: 32 mm
bolt hole: 13 mm
load capacity: 90 kg
dpvlink
8035

Product No.: 623.080.ELS
21.70 CHF
ESD Light duty swivel castor with bolt hole 550 - double stop load capacity 100 kg, heavy version
Wheel Ø: 125 mm /
ESD swivel castor 125 mm,
Series 550 / apparatus castor
Double stop/back hole, sheet steel housing,
with thread protection, rubber tyres black,
electrically conductive
Wheel width: 32 mm
back hole: 12.2 mm
loading capacity: 100 kg

A plasticizer diffusion can lead to a contact discoloration of the floor, approx. 80 ° -85 ° Shore A
dpvlink
10755

Product No.: 503.AK125.DS.EL
32.40 CHF
ESD Swivel castor with top plate 500, load capacity 50 kg
Load capacity (static): 50 kg / Wheel Ø: 80 mm / Total height: 100 mm /
ESD swivel castor 80 mm,
top plate 105x80mm,
Pressed steel bracket, electrically conductive

Wheel width: 30 mm
bores/plate: 80x60 mm
load capacity: 50 kg

A plasticizer diffusion can lead to a disoloration of the floor, hardness approx. 80 °-85 ° shore A
dpvlink
3278

Product No.: 524.080.EL
9.55 CHF
ESD Light duty swivel castor with bolt hole - "stop-fix", load capacity 150 kg
Load capacity (static): 150 kg / Wheel Ø: 100 mm / Total height: 121 mm /
ESD apparatus swivel castor 100 mm, bolt hole
thermoplastic rubber tread, non-marking grey
wheel body made of polypropylene,
brake "stop-fix SF" (DIN EN 61340-5-1)
Plate diameter: 43 mm
wheel width: 25 m
bolt hole: 11 mm
load capacity: 70 kg
dpvlink
8057

Product No.: 603.100-SF.ELS
16.90 CHF
17 to 32 (from a total of 104)
