Drying storage cabinet HSD 1106-52
(Product No.: TO-HSD-1106-52)
Mobile Preview: Image
Mobile Preview: Image
Mobile Preview: Image
Mobile Preview: Image
Mobile Preview: Image
Mobile Preview: Image
Mobile Preview: Image

Drying storage cabinet HSD 1106-52

dpvlink:
27401
Tags:
Shelves:
5
Volume:
1179 l
Width [mm]:
1200 mm
Height [mm]:
1675 mm
Depth [mm]:
658 mm
Further product information


Compare Compare
Notice
Product Info
Drying Cabinet HSD 1106-52 The drying cabinet with the item number TO-HSD-1106-52 offers an optimal solution for dry storage under strict environmental conditions. With a robust steel housing and 360° casters including brakes, this cabinet is mobile and can be securely positioned. The doors are lockable and meet protection class 1. The drying unit operates maintenance-free and keeps the relative humidity (RH) consistently below 0.5%. Additionally, the cabinet is ESD-safe and conforms to the ESD standard DIN EN 61340-5-1. Technical Data: - Volume: 1179 l - Dimensions (WxHxD): 1200 mm x 1675 mm x 658 mm - Interior dimensions (WxHxD): 1190 mm x 1533 mm x 630 mm - Weight: 189 kg - Load capacity: 300 kg - Number of shelves: 5, with a load capacity of 50 kg per shelf - Cable length: 5.0 m Additional features include an integrated data logger, Totech Viewer software, Ethernet interface, digital control panel, and forced air circulation. An integrated sensor ensures a measurement accuracy of +/- 0.8% RH with a fast recovery time of 15 minutes after door opening.
Shelves
Shelves
5
Volume
Volume
1179 l
Width [mm]
Width [mm]
1200 mm
Height [mm]
Height [mm]
1675 mm
Depth [mm]
Depth [mm]
658 mm
Cable length
Cable length
5.0 m
Internal depth
Internal depth
630 mm
Internal height
Internal height
1533 mm
Internal width
Internal width
1190 mm
Bracket
Bracket
steel sheet
Load capacity
Load capacity
300 kg
Weight
Weight
189 kg
Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Product Family

Article imageArticle descriptionShelvesVolumeWidth [mm]Height [mm]Depth [mm]PriceCompare
TO-HSD-1104-52 - Drying storage cabinet HSD 1104-52 TO-HSD-1104-52
Drying storage cabinet HSD 1104-52 		51179 l1200 mm1675 mm658 mm -
TO-HSD-1106-52 - Drying storage cabinet HSD 1106-52 TO-HSD-1106-52
Drying storage cabinet HSD 1106-52 		51179 l1200 mm1675 mm658 mm -
TO-HSD-1704-52 - Drying cabinet HSD 1704-52 TO-HSD-1704-52
Drying cabinet HSD 1704-52 		51700 l1200 mm1675 mm960 mm -
