Shielding bag DPV-1000 Zip "metal-in" 102 x 152 mm
Shielding Bag DPV-1000 Zip "metal-in" 102 x 152 mm
The DPV-1000 Zip "metal-in" shielding bag provides optimal protection for electronic components against electrostatic discharges (ESD). This resealable bag prevents static charging and thus protects ESD-sensitive components from damage. The multilayer structure with aluminum vapor deposition and amine-free polyethylene ensures high shielding against field induction and controlled dissipation of existing charges without causing spontaneous discharges. The bag is transparent, allowing a clear view of the contents and is suitable for assemblies with batteries and accumulators.
Technical Data:
- Dimensions: 102 x 152 mm
- Material thickness: 0.078 mm (78µm) according to DIN EN 61340-5-1
- Surface resistance Rs: 10^10 - 10^11 Ω
- Electrostatic shielding: <15 nJ
- Discharge time max.: 0.03 s
- Material: Polyethylene / Polyester, multilayer, amine-free
- Color: transparent
- Sealable and resealable
- Packaging unit: 100 pieces
Standards: MIL-PRF-81705D, ANSI/ESD STM 11.11, ANSI/ESD STM11.31, EIA 541, ASTM D882, ASTM D1003
Markings: ESD warning symbol, type designation, recycling symbol, RoHS compliance, LOT No.
Item number: D-1000.0406.ZIP
The DPV-1000 Zip "metal-in" shielding bag provides optimal protection for electronic components against electrostatic discharges (ESD). This resealable bag prevents static charging and thus protects ESD-sensitive components from damage. The multilayer structure with aluminum vapor deposition and amine-free polyethylene ensures high shielding against field induction and controlled dissipation of existing charges without causing spontaneous discharges. The bag is transparent, allowing a clear view of the contents and is suitable for assemblies with batteries and accumulators.
Technical Data:
- Dimensions: 102 x 152 mm
- Material thickness: 0.078 mm (78µm) according to DIN EN 61340-5-1
- Surface resistance Rs: 10^10 - 10^11 Ω
- Electrostatic shielding: <15 nJ
- Discharge time max.: 0.03 s
- Material: Polyethylene / Polyester, multilayer, amine-free
- Color: transparent
- Sealable and resealable
- Packaging unit: 100 pieces
Standards: MIL-PRF-81705D, ANSI/ESD STM 11.11, ANSI/ESD STM11.31, EIA 541, ASTM D882, ASTM D1003
Markings: ESD warning symbol, type designation, recycling symbol, RoHS compliance, LOT No.
Item number: D-1000.0406.ZIP
Details
- Width [mm] Width [mm]
- 102
- Length [mm] Length [mm]
- 152
- Thickness [mm] Thickness [mm]
- 0.078
- PU PU
- 100 piece
- reclosable reclosable
- yes
- Color Color
- transparent
- Conductivity Conductivity
- shielding
- Electrostatic shielding Electrostatic shielding
- <15 nJ
- Static decay time max. Static decay time max.
- 0.03 s
- Surface resistance Rs Surface resistance Rs
- 1010 - 1011 Ω
- amine-free amine-free
- yes
- Material Material
- polyethylene / polyester
- heat-sealable heat-sealable
- yes
- Layers Layers
- multilayer
Downloads
- Please log in to download datasheets! :
- There are several datasheets for this product. Please log in!
Catalogues
Product Family
Article image
Article description
Width [mm]
Length [mm]
Thickness [mm]
PU
reclosable
Price
Compare
102
152
0.078
100 piece
yes
76
127
0.078
100 piece
yes
127
203
0.078
100 piece
yes
152
254
0.078
100 piece
yes
356
457
0.078
100 piece
yes
203
254
0.078
100 piece
yes
152
203
0.078
100 piece
yes
254
305
0.078
100 piece
yes
305
406
0.078
100 piece
yes
203
305
0.078
100 piece
yes
254
356
0.078
100 piece
yes
406
457
0.078
100 piece
yes
