End cutting pliers 3784
End cutting pliers 3784
The front cutter 3784 from CK is a highly specialized tool designed for precise cuts in hard materials such as wire, nails, or thin metal rods. This robust front cutter features a durable construction made of special alloy steel, which has been drop-forged, hardened, and tempered to ensure exceptional strength and durability.The precise through-riveted joint construction ensures lasting, adjustment-free jaw alignment, while the induction-hardened jaws provide excellent long-term performance. The high-gloss polished surface protects against corrosion and prevents chrome flaking, making maintenance easier. Ergonomically shaped dual-component handles offer enhanced comfort and control, ideal for use in electronics manufacturing, crafts, and metalworking.
Fully ESD compliant according to IEC 61340-5.1 and 5.2, the front cutter guarantees safe use on sensitive electronic components. With an overall length of 130 mm and a tapered head shape, this tool enables precise cuts in tight areas. The blade length is 20 mm and the head width is 10 mm, which, together with the polished surface and the spot-welded double leaf spring, ensures reliable and repeatable cutting movements.
Details
- Bevel Bevel
- without bevel
- Head type/size Head type/size
- regular
- Head shape Head shape
- oblique / tapered
- Max Ø soft Max Ø soft
- 0.81 mm
- Max Ø medium Max Ø medium
- 0.64 mm
- AWG medium AWG medium
- 22
- AWG soft AWG soft
- 20
- Head thickness Head thickness
- 6 mm
- Blade length Blade length
- 4 mm
- Length Length
- 130 mm
- Material Material
- steel
- Surface Surface
- polished
- ESD ESD
- yes
- Head width Head width
- 10 mm
- Jaw length Jaw length
- 20 mm
- Type of pliers Type of pliers
- end cutting pliers
- Version Version
- with opening spring
The current composition of shape and technology, completely convincing.
A flowing line adapted to the natural form of the hand in the right proportions.
The guarantee for a fatigue-free, controlled, safe and fast working in a level of quality that has been unknown up to now.
Ergonomics in an optimum design.
- Two-component handle with flush, soft thermoplastic material, slip-resistant and comfortable.
- Slip protection for a controlled and concentrated work.
- Captive, welded double leaf spring: guarantees an optimal function for the whole service life.
- Precise box joint: accurate guiding of the jaws without readjustment in case of a long service life.
- Mirror polish: optimal protection against corrosion without chrome, easy to clean.
- Inductive hardening of cutting edges: high hardness for a long durability.
The shapes of cutting edges and cutting performance
With small bevel (facet)
Normal cut. Suitable for cutting hard and soft steel wires as well as soft materials such as copper wire and cable.
With large bevel (facet)
Suitable for cutting hard and very hard steel wires. Long service life.
Without bevel (facet)
Flush cut. Extremely sharp cutting edges. Only suitable for soft steel wires, copper wire and cable.
Made in Germany
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.
Without bevel
Specially shaped cutting edge that is curved inwards. Flush cut. Only for soft materials such as fine wires.
Downloads
- Please log in to download datasheets! :
- There are several datasheets for this product. Please log in!
Catalogues
Product Family
Article image
Article description
Bevel
Head type/size
Head shape
Max Ø soft
Max Ø medium
Price
Compare
without bevel (flush cut)
regular
oblique
2.05 mm
1.63 mm
