A forged precision joint and a low-friction double spring allow for smooth and even opening. The cutting edges of the diagonal cutter are additionally laser-hardened and achieve a hardness of at least 56 HRC, ensuring high cutting performance and durability. The mirror-polished surface with a fine oil film effectively protects against rust and prevents circuit disruptions due to flaking chrome parts.
The handles are equipped with two-tone multi-component sleeves in black/gray, which ensure ergonomic handling. With an overall length of 115 mm and a weight of only 70 g, the diagonal cutter is handy and efficient in use. It is designed for cutting soft materials up to 2.0 mm, medium-hard materials up to 0.81 mm, and hard materials up to 0.5 mm in diameter.
This tool made of high-quality tool steel is thus the ideal choice for precise and demanding cutting tasks.
Details
- Bevel Bevel
- small bevel
- Max Ø soft Max Ø soft
- 2.0 mm
- Max Ø medium Max Ø medium
- 0.81 mm
- Max Ø hard Max Ø hard
- 0.5 mm
- Head thickness Head thickness
- 7 mm
- Blade length Blade length
- 16 mm
- Height [mm] Height [mm]
- 17 mm
- Length [mm] Length [mm]
- 115 mm
- Width [mm] Width [mm]
- 66 mm
- Material Material
- Tool steel
- Surface Surface
- mirror polished
- ESD ESD
- yes
- Head shape Head shape
- oblique
- Head width Head width
- 11 mm
- Jaw length Jaw length
- 6 mm
- Type of pliers Type of pliers
- End cutting pliers
- Weight Weight
- 70 g
The cutting pliers of the Knipex standard series are equipped with precision-ground cutting edges for finest cutting work, e.g. in electronics and fine mechanics. A low-friction double spring ensures a smooth and even opening. The mirror polish combined with a fine oil film offers a good rust protection so that errors in circuits by flaking chrome parts are prevented.
All versions are electrically dissipative
Knipex pliers comply with the highest requirements concerning performance, ergonomics, and service life.
Due to a special selection of the used steels and the careful and high-quality processing, the Knipex pliers achieve an optimal durability and service life. Innovative ideas always offer forward-looking solutions for an easy, effective and safe working.
The cutting shapes and cutting performance:
With mini bevel (facet)
Nearly flush cut. Fine cutting edges. Suitable for soft steel wire, copper wire and cable.
With small bevel (facet)
Normal cut. Suitable for cutting hard and soft steel wires as well as soft materials such as copper wire and cable.
With large bevel (facet)
Suitable for cutting hard and very hard steel wires. Long service life.
Without bevel (facet)
Flush cut. Extremely sharp cutting edges. Only suitable for soft steel wires, copper wire and cable.
Without bevel flush (facet)
Flush cut for soft materials.
