The image shows an adapter with two silver pins and a black, ergonomically shaped handle. The upper part has a connection that resembles a USB port.
Soldering tip pair blade tip RTWUS 060 K
(Product No.: 501.170.99)
The image shows an adapter with two silver pins and a black, ergonomically shaped handle. The upper part has a connection that resembles a USB port.
Notice

Soldering tip pair blade tip RTWUS 060 K

Soldering tip pair blade tip RTWUS 060 K

dpvlink:
27477
Further product information

104.25 CHF

excl. 8.1% tax

1 PCE
Compare Compare
Notice
Product Info

Soldering tip pair blade tip RTWUS 060 K

The Weller RTWUS 060 K soldering tip pair is specifically designed for the WXUTS desoldering tweezers and is characterized by its precise knife-edge tips. These tips have a width of 6.0 mm and a length of 29.6 mm, which allows for precise and efficient heat transfer. The dual tip configuration, with 75 watts of power at a voltage of 24 volts, ensures a quick heat-up time of only 10 seconds and a broad temperature range of 100 to 450 °C.
The soldering tip pair is part of the RTWUS series and ideal for demanding soldering tasks where precision and rapid work are required. The robust construction and high-quality workmanship guarantee a long lifespan and reliability in daily use.
Power
Power
75 / 75 W
Voltage
Voltage
24 V
Length
Length
29.6 mm
Tip width
Tip width
6.0 mm
Soldering tip series
Soldering tip series
RTWUS
Soldering tip shape
Soldering tip shape
blade tip
suitable soldering iron
suitable soldering iron
WXUTS
Heating-up time
Heating-up time
10 s
Temperature range
Temperature range
100 - 450 °C
Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Product Family

RTWUS Ultra soldering tips pair blade tip

Article image
Article description
Power
Voltage
Length
Tip width
Soldering tip series
Soldering tip shape
suitable soldering iron
Heating-up time
Temperature range
Price
Compare
501.170.99 - Soldering tip pair blade tip RTWUS 060 K
501.170.99
Soldering tip pair blade tip RTWUS 060 K
75 / 75 W
24 V
29.6 mm
6.0 mm
RTWUS
blade tip
WXUTS
10 s
100 - 450 °C
104.25 CHF
501.171.99 - Soldering tip pair blade tip RTWUS 100 K
501.171.99
Soldering tip pair blade tip RTWUS 100 K
75 / 75 W
24 V
29 mm
10.0 mm
RTWUS
blade tip
WXUTS
10 s
100 - 450 °C
104.25 CHF
501.172.99 - Soldering tip pair blade tip RTWUS 200 K
501.172.99
Soldering tip pair blade tip RTWUS 200 K
75 / 75 W
24 V
29 mm
20.0 mm
RTWUS
blade tip
WXUTS
10 s
100 - 450 °C
125.30 CHF
501.173.99 - Soldering tip pair blade tip RTWUS 150 K
501.173.99
Soldering tip pair blade tip RTWUS 150 K
75 / 75 W
24 V
29 mm
15.0 mm
RTWUS
blade tip
WXUTS
10 s
100 - 450 °C
114.80 CHF
