The image shows a garden or plant pliers with two long, curved handles. The pliers have a metal clip with a spring and a sharp edge for cutting branches or stems.
The image shows a technical drawing of a tool, likely a crimping tool. Dimensions and scales are marked. The tool has a round handle and a pointed opening.
Preview: The image shows a garden or plant pliers with two long, curved handles. The pliers have a metal clip with a spring and a sharp edge for cutting branches or stems.
Preview: The image shows a technical drawing of a tool, likely a crimping tool. Dimensions and scales are marked. The tool has a round handle and a pointed opening.
Stripping tool CSP.30.2.D
(Product No.: CSP-30.2.D)
The image shows a garden or plant pliers with two long, curved handles. The pliers have a metal clip with a spring and a sharp edge for cutting branches or stems.
The image shows a technical drawing of a tool, likely a crimping tool. Dimensions and scales are marked. The tool has a round handle and a pointed opening.
Mobile Preview: The image shows a garden or plant pliers with two long, curved handles. The pliers have a metal clip with a spring and a sharp edge for cutting branches or stems.
Mobile Preview: The image shows a technical drawing of a tool, likely a crimping tool. Dimensions and scales are marked. The tool has a round handle and a pointed opening.
Notice / Inquire

Stripping tool CSP.30.2.D

dpvlink:
2285
Properties:
Further product information

13.60 CHF

excl. 8.1% tax

1 PCE
Compare Compare
Notice / Inquire
Product Info

Stripping tool CSP.30.2.D

The Piergiacomi CSP.30.2.D stripping tool is a durable multipurpose tool specifically designed for technical applications. It combines the functions of scissors, a cable stripper, and pliers in a single tool. This model is designed to be ESD-dissipative according to DIN EN 61340-5-1 and is therefore particularly suitable for use in ESD-protected areas.
The total length of the tool is 165 mm, while the blade has a length of 40 mm. The head width is 29.5 mm, allowing for precise handling. The tool is designed for cables with a copper diameter of 0.81 to 2.59 mm and a cross-section of 20 to 10 AWG. Weighing only 102 g, it is lightweight and thus ideal for longer periods of use without user fatigue.
In summary, the CSP.30.2.D is a highly functional tool that provides reliability and precision for professional applications.
AWG
AWG
20 - 10
Max Ø soft
Max Ø soft
2.59 mm
Length
Length
165 mm
ESD
ESD
yes
Head width
Head width
29.5 mm
Jaw length
Jaw length
40 mm
Weight
Weight
102 g
Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 488
Complete Catalog 2023 - 2024

Product Family

Stripping tool SF-30.D

Article image
Article description
AWG
Max Ø soft
Blade length
Length
ESD
Head width
Jaw length
Weight
Price
Compare
SF-30.D - Stripping tool SF-30.D
SF-30.D
Stripping tool SF-30.D
32 - 22
0.64 mm
8 mm
141 mm
yes
14 mm
20 mm
78 g
18.80 CHF
SFF-30.D - Stripping tool SFF-30.D
SFF-30.D
Stripping tool SFF-30.D
28 - 24
0.51 mm
8 mm
141 mm
yes
14 mm
20 mm
76 g
18.65 CHF
CSF-30.D - Stripping tool CSF 30.D
CSF-30.D
Stripping tool CSF 30.D
26 - 16
1.3 mm
18.5 mm
144 mm
yes
17.0 mm
18.5 mm
80 g
19.00 CHF
CSP-30.1.D - Stripping tool CSP 30.1.D
CSP-30.1.D
Stripping tool CSP 30.1.D
30 - 20
0.81 mm

165 mm
yes
29.5 mm
41 mm
102 g
14.00 CHF
CSP-30.2.D - Stripping tool CSP.30.2.D
CSP-30.2.D
Stripping tool CSP.30.2.D
20 - 10
2.59 mm

165 mm
yes
29.5 mm
40 mm
102 g
13.60 CHF
